ZMC RS-SF1-8 Flat Internal Shade Hem Bar - 8 Foot (94" Actual Length)

Shade hem bars are used at the bottom of a shade to help keep the shade flat while it is hanging. Internal hem bars are typically concealed in a pocket formed by folding the shade material. Traditionally, wood or aluminum is used for shade or blind hems. Aluminum provides the benefit of resistance to warp, strength and increased weight. Large shades and stiff shade materials require the use of heavier ham bars.

The ZMC RS-SF1 profiled aluminum internal hem bar features a nicely curved front face, rounded edges and is a somwhat tall compared to the alternatives. This hem bar is preffered by many shade manufacturers as it can be used for both small and large shades.

ZMC RS-SF1-8 Aluminum Internal Hem Bar Specifications - 8 Foot (94" Actual):
   •  Length: 94" - (+/-0.125")
   •  Height: 1"
   •  Thickness: 0.12"
   •  Weight: 0.14 lb per foot
   •  Material: Aluminum
   •  Finish: As Extruded
   •  Shape: Flat
   •  Stocked in 16 foot lengths

Optional: FREE custom cut lengths cut to an accuracy of 1/16" +/- 1/32.

Lengths longer than 94" will need to be purchased as 9 Foot Lengths (106" actual) due to shipping costs based on package lengths.
